Views: 0 Author: Site Editor Publish Time: 2025-05-30 Origin: Site
In industrial materials sourcing, “high-density polyurethane foam” is a widely used term referring to foam materials with excellent compression resistance, thermal insulation, or structural support performance.
At XYFoams, we specialize in microcellular polyurethane foam solutions with densities ranging from 60 kg/m³ to 600 kg/m³, precisely engineered for use in new energy vehicle battery systems, 3C electronics, railway infrastructure, and industrial equipment.
Whether you require ultra-thin, soft, adhesive-backed foam for sensor sealing, or rigid, high-density foam for battery pack structural support, we can tailor the formulation, density, and performance level to your exact application scenario.
Foam performance must be matched to the functional environment—not judged by density alone.
| Density Range (kg/m³) | Recommended Series | Typical Applications |
|---|---|---|
| 200–320 | USF-PSD, PSS BTP | Camera trim rings, dust-proof gaskets, ultra-light cushioning |
| 250–320 | USF-PMD, PSS BT1/2 | Display cushioning, ultra-thin sealing, PCB protection pads |
| 200–600 | USF-PFT, USF-PST | Wearables, slow/fast rebound keypads, structural gaskets |
| 320 | INF-MH32 | Battery module sidewall buffers, cold plate support |
| 320–400 | INF-HH32, INF-HH40 | Structural support, prismatic cell insulation & buffering |
| 320–480 | USF-PHD | Load-bearing pads, railway equipment vibration damping |
✅ Uniform microcellular structure, stable load distribution
✅ Semi-closed cell foam: excellent sealing, waterproofing, dust-proofing
✅ Wide compression stress range: ≤400 KPa
✅ Low compression set: ≤5% (50% compression @ 70°C, 22h)
✅ Thickness range: 0.1 mm – 8.0 mm
✅ Flame resistance: UL94 HF-1 / V-0 (selected models)
✅ Compliant with RoHS and REACH
✅ Certified under ISO9001 / IATF16949 and more
Use Cases:
Inter-cell insulation and cushioning
Module bottom padding and support
Liquid cooling plate support & sidewall filling
Recommended Models: INF-MH32, INF-HH32, INF-HH40
Density: 320–450 kg/m³
Compression Stress: 40–400 KPa
Flame Rating: HBF / HF-1 / V-0 (≥6 mm)
Use Cases:
Speaker cushioning
Display back padding
Dust-proof camera rings
Battery covers and motherboard area filling
Recommended Models: USF-PMD, USF-PSD, USF-PST, PSS BTP/BT1/2
Thickness: 0.1 mm – 2.0 mm
Features: Soft, flexible, with/without adhesive, optional breathable adhesive
Use Cases:
Buffer pads within vehicle bodies
High-load anti-vibration blocks
Sound absorption & structural support
Recommended Models: INF-STR20, USF-PHD
Density: 200–450 kg/m³
Compression Stress: 100–600 KPa
Flame Rating: HF-1 / V-0 (≥3 mm)
| Model | Compression @ 25% (KPa) | Density (kg/m³) | Thickness (mm) | Flame Rating | Key Application |
|---|---|---|---|---|---|
| INF-HH40 | 70–250 | 400 | 0.6–4.0 | HF-1 / V-0 | Battery structure support foam |
| INF-HH32 | 70–150 | 320 | 0.7–6.0 | HF-1 / V-0 | Cooling plate base, module center support |
| INF-MH32 | 40–100 | 320 | 0.7–6.0 | HF-1 | Thermal barrier and buffer between cells |
| USF-PMD | 7–35 | 250 | 0.2–2.0 | / | Display pad, motherboard cushioning |
| USF-PSD | 2–17 | 200 | 0.2–2.0 | / | Lens trim ring, dust-proof buffer |
| USF-PST (Slow Rebound) | 8–170 | 320–600 | 0.2–4.5 | / | Keypads, wearable cushioning |
| USF-PHD | 120–360 | 480 | 0.4–2.0 | / | Heavy-load pads, rail base damping |
| PSS BTP/BT1/BT2 | 15–80 | 320–450 | 0.1–0.2 | / | Ultra-thin sealing, adhesive/breathable adhesive available |
Max Width: 520 mm
Thickness Range: 0.1 mm – 8.0 mm
Standard Roll Diameter: ≤300 mm
Core Spec: 3-inch inner diameter, 4 mm wall
Processing Services: die-cutting, lamination, slitting, PET lamination
Adhesive Systems Available: silicone-based, acrylic, breathable tape
Certified: ISO9001 / ISO14001 / IATF16949 / ISO45001
RoHS & REACH Compliant
UL94 HF-1 / V-0 flame ratings (≥6 mm)
Tight control over compression set, thermal stability, dimensional consistency
Looking for high-performance microcellular PU foam with stable density, compression strength, and flame resistance?
We’re here to help with product selection, custom samples, and technical support.
